Lab Work 3 (Part 1)
Implementing Sequential Logic
Sequential logic circuits mainly provides storage for a digital system. Thus, for example, it allows implementation of processes that need the previous state of a digital logic.
Only two basic types of sequential logic circuit:
- Latch : level-triggered temporary storage device with 2 stable states
- Flip-flop : edge-triggered storage device
Note: We will be using the button (@reset) switch (instead of the normal toggle DIP-switch). Try to find out why this is a better option.
Implementing Latches
For a basic latch, it needs to have the means to achieve any stable state (HI or LO) at its output and to maintain that output state.
S-R Latch
|
A basic S-R Latch:
|
Truth table:
Note: '*' indicates invalid condition |
Disclaimer: The image above is extracted from resources available for Digital Fundamentals 11th Edition (Global Edition)
Notice that the invalid condition will happen when the S & R inputs are both at logic 1. In a real digital system, we need to prevent this from happening.
Gated S-R Latch
A gated S-R Latch:
Disclaimer: The image above is extracted from resources available for Digital Fundamentals 11th Edition (Global Edition)
Truth table for a S-R Latch:
| | | | | |
|---|---|---|---|---|
| 0 | 0 | 0 | | |
| 0 | 1 | 0 | | |
| 1 | 0 | 0 | | |
| 1 | 1 | 0 | | |
| 0 | 0 | 1 | | |
| 0 | 1 | 1 | 0 | 1 |
| 1 | 0 | 1 | 1 | 0 |
| 1 | 1 | 1 | 1 | 1 |
Note:Output in BOLD is an invalid condition.
Gated D Latch
A gated D Latch:
Disclaimer: The image above is extracted from resources available for Digital Fundamentals 11th Edition (Global Edition)
Truth table for a gated D Latch:
| | | | |
|---|---|---|---|
| 0 | X | | |
| 1 | 0 | 0 | 1 |
| 1 | 1 | 1 | 0 |
Implementing Flip-flops
Unlike latches, flip-flops requires reference clock signal that is used to transfer whatever signal at its input to its internal storage (latch).
D Flip-flop
A D flip-flop (DFF) can be built using two opposite level-triggered gated D latches. This is known as a master slave DFF, as shown in figure below. Is this a positive or negative edge-triggered DFF?
Disclaimer: The image above is obtained from Wikipedia
Truth table for a positive edge-triggered DFF:
| | | | |
|---|---|---|---|
| 0→1 | 0 | 0 | 1 |
| 0→1 | 1 | 1 | 0 |
The table for negative edge-triggered DFF onlly differs at CLK column with 1→0 instead of 0→1.
J-K Flip-flop
Truth table for a J-K Flip-flop:
| | | | | |
|---|---|---|---|---|
| 0 | 0 | 0→1 | | |
| 0 | 1 | 0→1 | 0 | 1 |
| 1 | 0 | 0→1 | 1 | 0 |
| 1 | 1 | 0→1 | | |
Notice that, unlike DFF, J-K FF has a toggle mode.
T Flip-flop
The DFF can easily be modified to act as a Flip-flop that toggles on clock edges - by simply connecting the output to the
input.
Things To Do
THING1 Build an S-R Latch (use NOR gates) and verify.
THING2 Build a gated S-R Latch (use NAND gates) and verify.
THING3 Build a gated D Latch and verify.
THING4 Build a D Flip-flop (DFF) and verify.
THING5 Build a J-K Flip-flop and verify.
THING6 (optional) Try to verify the use of DFF as a frequency divider.
